MUSHclient with open-source tools

This guide outlines the implementation of a persistent Lua-based plugin for MUSHclient. It focuses on creating a data-driven system that captures MUD output via regular expressions, stores state across sessions using the built-in variable system, and utilizes lifecycle hooks for clean initialization.

45-60 minutes6 steps
MUSHclient with open-source tools illustration
Placeholder illustration shown while custom artwork is being produced.
1

Define the Plugin Metadata Header

Create a new .xml file in the /worlds/plugins directory. Every MUSHclient plugin requires a unique 24-character ID and specific attributes to identify itself to the client engine.

HealthTracker.xml
<include name="Constants.lua"/>
<plugin
   name="HealthTracker"
   author="Developer"
   id="a1b2c3d4e5f6g7h8i9j0k1l2"
   language="Lua"
   purpose="Tracks HP and Mana via triggers"
   save_state="y"
   version="1.0"
   >
</plugin>

⚠ Common Pitfalls

  • •Duplicate IDs will cause the client to ignore the plugin.
  • •Ensure save_state is set to 'y' or variables will not persist on disk.
2

Initialize the Lua Script Block

Open a <script> tag within the XML. This is where the Lua logic resides. Use the OnPluginInstall callback to initialize global tables and load existing data.

<script>
<![CDATA[
function OnPluginInstall()
    Note("HealthTracker plugin loaded.")
    hp = tonumber(GetVariable("current_hp")) or 0
    max_hp = tonumber(GetVariable("max_hp")) or 0
end
]]>
</script>

⚠ Common Pitfalls

  • •Variables retrieved via GetVariable are always strings; tonumber() is required for math operations.
  • •CDATA tags are essential to prevent the XML parser from breaking on Lua symbols like < or &.
3

Implement Regex Triggers for Data Capture

Define triggers within the XML (outside the script block) to capture MUD output. Use named groups or wildcards to pass data to a Lua function.

<triggers>
  <trigger
   enabled="y"
   match="^HP: (\d+)/(\d+) MP: (\d+)/(\d+)>"
   regexp="y"
   script="OnStatsUpdate"
   sequence="100"
  >
  </trigger>
</triggers>

⚠ Common Pitfalls

  • •Incorrect sequence numbers can cause other plugins to intercept lines first.
  • •Ensure the 'regexp' attribute is set to 'y' if using PCRE patterns.
4

Process Captured Data in Lua

Write the callback function defined in the trigger. This function receives wildcards from the regex match. Update the local state and perform logic like low-health warnings.

function OnStatsUpdate(name, line, wildcards)
    hp = tonumber(wildcards[1])
    max_hp = tonumber(wildcards[2])

    if hp < (max_hp * 0.2) then
        ColourNote("red", "black", "WARNING: LOW HEALTH!")
    end
end

⚠ Common Pitfalls

  • •Wildcard indices start at 1 in MUSHclient Lua, unlike 0-indexed arrays in other languages.
  • •Excessive use of Note() or ColourNote() in high-frequency triggers can cause client lag.
5

Configure State Persistence

To ensure data survives a client restart or plugin reload, use OnPluginSave to write variables back to the plugin's internal database.

function OnPluginSave()
    SetVariable("current_hp", hp)
    SetVariable("max_hp", max_hp)
end

⚠ Common Pitfalls

  • •SetVariable only accepts strings or numbers; tables must be serialized using a helper or JSON-like stringification.
  • •If the plugin crashes before OnPluginSave is called, data from that session is lost.
6

Debug via the Global Trace Window

Use the built-in MUSHclient trace functionality to debug trigger matches. Press Ctrl+Alt+T or use script commands to inspect which triggers are firing and why they might fail to match.

-- Add this to your logic to force a trace during testing
SetEntityCheck(true)
Trace(true)

⚠ Common Pitfalls

  • •Leaving Trace(true) active in a production plugin will flood the output window and degrade performance.

What you built

By following this structure, you have created a modular MUSHclient plugin that separates trigger definitions from Lua logic while maintaining state. This architecture is scalable for complex UI overlays, automated combat systems, or inventory management scripts.
